MK Vertical multi-stage pump
INSTALLATION AND USE Suitable for use with clean water and liquids that are not chemically aggressive towards the materials from which the pump is made. The high efficiency and adaptability of these pumps to even the most unusual of applications, makes them ideal for use in the domestic, civil and industrial sectors; in particular for the distribution of water in combination with pressure sets and for pressure boosting.
The pump should be installed in an enclosed environment, or at least sheltered from inclement weather. FEATURES Liquid type: clean water Uses: domestic, civil, industrial
APPLICATIONS: water supply systems, fire-fighting sets, washing systems, pressure systems, irrigation pumps. Typology: surface Family: vertical multistage pumps
APPLICATION LIMIT: Temperature of the liquid from -10 °C to +40 °C Ambient Temperature to +40 °C Manometric suction lift up to 7 m Max. working pressure 10 bar Continuous service S1
Model: MKm 5/5Power Supply: Single Phase 230V 50HzkW: 1,5Hp: 2Flow Rate Q L/min: 20 ÷ 120Head H Metres: 64 ÷ 29Aspiration: 1¼"Outlet: 1"Power Cable: NOT ProvidedPump Body: Cast Iron and Stainless Steel AISI 304Impeller: NorylMotor Efficiency Class: -
